30 Stk. an Lager
Indexable insert
Regular price:
CHF 22.15
Item original number:
LPNT 060204EN AM5035
Item number:
824923
Technical documents:
Delivery time: 1-3 days
Product information "Indexable insert"
| Area of application: | M1 Stainless steel ≤700 N/mm²M2 Stainless steel ≤750 N/mm²M3 Stainless steel ≤850 N/mm²M4 Stainless steel ≤950 N/mm²M5 Stainless steel ≤1250 N/mm²P1 Steel ≤500 N/mm²P2 Steel 500-700 N/mm²P3 Steel 600-800 N/mm²P4 Steel 800-1000 N/mm²P5 Steel 900-1200 N/mm²P6 Steel 1200-1600 N/mm²S1 HRSA ≤25 HRCS2 HRSA 25-35 HRCS3 HRSA 35-45 HRCS4 Low alloy titaniumS5 High alloy titanium |
|---|---|
|
Area of application (●ideal / ◌appropriate): |
◌ P1 Steel ≤500 N/mm²◌ P2 Steel 500-700 N/mm²◌ P3 Steel 600-800 N/mm²◌ P4 Steel 800-1000 N/mm²◌ P5 Steel 900-1200 N/mm²◌ P6 Steel 1200-1600 N/mm²◌ S1 HRSA ≤25 HRC◌ S2 HRSA 25-35 HRC◌ S3 HRSA 35-45 HRC◌ S4 Low alloy titanium◌ S5 High alloy titanium● M1 Stainless steel ≤700 N/mm²● M2 Stainless steel ≤750 N/mm²● M3 Stainless steel ≤850 N/mm²● M4 Stainless steel ≤950 N/mm²● M5 Stainless steel ≤1250 N/mm² |
| Coating / Suface: | AM5035 |
| Corner radius: | 0.4 |
| Cutting insert height: | 2.38 |
| Géométrie: | Universal |
| Insert size: | 06 |
| Manufacturer: | Arno |
| Substrate: | VHM |
| Tool type: | Inserts |
| Type of insert: | LPNT |
