30 Stk. an Lager
Carbide inserts SNMX 120508EN-NMR AM5740
Regular price:
CHF 22.46
Item original number:
SNMX 120508EN-NMR AM5740
Item number:
824870
CAD data
Technical documents:
Delivery time: 1-3 days
Product information "Carbide inserts SNMX 120508EN-NMR AM5740"
| Area of application: | M1 Stainless steel ≤700 N/mm² M2 Stainless steel ≤750 N/mm² M3 Stainless steel ≤850 N/mm² M4 Stainless steel ≤950 N/mm² M5 Stainless steel ≤1250 N/mm² S1 HRSA ≤25 HRC S2 HRSA 25-35 HRC S3 HRSA 35-45 HRC S4 Low alloy titanium S5 High alloy titanium |
|---|---|
|
Area of application (●ideal / ◌appropriate): |
◌ S1 HRSA ≤25 HRC ◌ S2 HRSA 25-35 HRC ◌ S3 HRSA 35-45 HRC ◌ S4 Low alloy titanium ◌ S5 High alloy titanium ● M1 Stainless steel ≤700 N/mm² ● M2 Stainless steel ≤750 N/mm² ● M3 Stainless steel ≤850 N/mm² ● M4 Stainless steel ≤950 N/mm² ● M5 Stainless steel ≤1250 N/mm² |
| Chip breaker: | NMR |
| Clearance angle: | N 0° |
| Coating / Suface: | PVD |
| Corner radius: | 0.8 |
| Fixing and geometry: | X |
| Grade: | AM5740 |
| Identification to ISO: | SNMX 120508 |
| Insert shape: | S 90° |
| Insert size: | 12 |
| Insert thickness: | 5.56 |
| Length of main cutting edge: | 12.7 |
| Manufacturer: | Arno |
| Substrate: | VHM |
| Tolerances: | M |
| Type of insert: | SNMX |
