80 Stk. an Lager
Carbide inserts SNGX 1205ZZ AP5230
CHF 27.25*
Item original number:
SNGX 1205ZZ AP5230
Item number:
824867
Technical documents:
Delivery time: 1-3 days
Product information "Carbide inserts SNGX 1205ZZ AP5230"
| Area of application: | K1 Grey cast iron 150-250 HB K2 Nodular cast iron 150-350 HB K3 Austenitic cast iron ≤260 HB K4 ADI cast iron 250-500 HB M1 Stainless steel ≤700 N/mm² M2 Stainless steel ≤750 N/mm² M3 Stainless steel ≤850 N/mm² M4 Stainless steel ≤950 N/mm² M5 Stainless steel ≤1250 N/mm² P1 Steel ≤500 N/mm² P2 Steel 500-700 N/mm² P3 Steel 600-800 N/mm² P4 Steel 800-1000 N/mm² P5 Steel 900-1200 N/mm² P6 Steel 1200-1600 N/mm² |
|---|---|
|
Area of application (●ideal / ◌appropriate): |
● K1 Grey cast iron 150-250 HB ● K2 Nodular cast iron 150-350 HB ● K3 Austenitic cast iron ≤260 HB ● K4 ADI cast iron 250-500 HB ● M1 Stainless steel ≤700 N/mm² ● M2 Stainless steel ≤750 N/mm² ● M3 Stainless steel ≤850 N/mm² ● M4 Stainless steel ≤950 N/mm² ● M5 Stainless steel ≤1250 N/mm² ● P1 Steel ≤500 N/mm² ● P2 Steel 500-700 N/mm² ● P3 Steel 600-800 N/mm² ● P4 Steel 800-1000 N/mm² ● P5 Steel 900-1200 N/mm² ● P6 Steel 1200-1600 N/mm² |
| Clearance angle: | N 0° |
| Coating / Suface: | PVD |
| Fixing and geometry: | X |
| Grade: | AP5230 |
| Identification to ISO: | SNGX 1205ZZ |
| Insert shape: | S 90° |
| Insert size: | 12 |
| Insert thickness: | 5.56 |
| Length of main cutting edge: | 12.7 |
| Manufacturer: | Arno |
| Substrate: | VHM |
| Tolerances: | G |
| Type of insert: | SNGX |
